ΦPRODUCT INTRODUCTION
Our wooden spool has excellent durability and stability. After strict quality and durability testing, our products can guarantee a long service life and stable performance. We pay attention to every detail to ensure that each spool meets the highest quality standards.
|
Product Name
|
Wooden Cable Reel |
|
Material
|
high quality pine |
|
Grade
|
New Material
|
|
Logo
|
Customizable
|
|
Size
|
Customizable
|
|
Disinfect
|
No/yes(can choose)
|
|
Bottom Structure
|
Plane Non-slip
|
| Glue |
WBP,E2 |
| Moisture |
12% |
|
Durability
|
High Durability
|
ΦFeatures
1. It has characteristics such as corrosion resistance, wear resistance, cold resistance, oil resistance, and softness, and can be used in any weather conditions, making it convenient and cost-effective.
2. The bending radius of the drum is small, requiring the cable material to have high flexibility and a small outer diameter.
3. Wooden cable reels are usually made of high-quality wood, which is sturdy, durable, and has strong load-bearing capacity.
4. The surface of the reel has a spiral texture, making it easy to unfold and roll up the cable.
5. Equipped with bearing seats and handles, it can prevent the drum from sliding or tilting during transportation and facilitate movement.
6. It has environmental performance and meets the fire protection requirements of modern buildings and power facilities.
| Description |
Flange Diameter(mm) |
Barrel Diameter(mm) |
Traverse / Inner width
(mm)
|
Loading capacity
(kg)
|
| 600*300*358 |
600 |
300 |
358 |
400 |
| 700*350*358 |
700 |
350 |
358 |
400 |
| 800*350*358 |
800 |
350 |
358 |
600 |
| 900*450*458 |
900 |
450 |
458 |
800 |
| 1000*500*558 |
1000 |
500 |
558 |
1000 |
| 1100*500*558 |
1000 |
500 |
558 |
1000 |
| 1200*700*680 |
1200 |
700 |
680 |
1200 |
| 1300*700*680 |
1300 |
700 |
680 |
1500 |
| 1400*700*680 |
1400 |
700 |
680 |
2000 |
| 1500*800*680 |
1500 |
800 |
680 |
2000 |
| 1660*800*810 |
1660 |
800 |
810 |
2500 |
| 1760*900*810 |
1760 |
900 |
810 |
3000 |
| 1760*900*810 |
1760 |
900 |
810 |
3500 |
| 1960*1200*980 |
1960 |
1200 |
980 |
3500 |
| 2060*1200*1030 |
2060 |
1200 |
1030 |
3500 |
| 2160*1200*1080 |
2160 |
1200 |
1080 |
4000 |
| 2260*1300*1130 |
2260 |
1300 |
1130 |
4000 |
| 2360*1300*1180 |
2360 |
1300 |
1180 |
4000 |
| 2460*1300*1230 |
2460 |
1300 |
1230 |
4000 |
| 2560*1300*1280 |
2560 |
1300 |
1280 |
4000 |
| 2600*1400*1400 |
2600 |
1400 |
1400 |
5000 |
| 2800*1400*1500 |
2800 |
1400 |
1500 |
5000 |
ΦFACTORY INTRODUCTION
Renqiu HONGFEI Wood Industry Co., Ltd. Is a large, fully qualified product packaging production enterprises, with inspection and quarantine certificate, printing and packaging license and other full set of industry qualifications. The main products include fumigated pallets, non-fumigated wood pallets, export wood pallets, domestic transshipment wood pallets, European standard pallets, wood packing boxes, wooden cable shafts and customized color printing cartons and cartons.
The company has standardized management, advanced packaging equipment, professional management personnel, excellent working environment, no pollution, professional supporting large workshop, warehouse extreme heat treatment warehouse
My company is willing to high quality, high performance products sincerely serve every customer!
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
ΦFAQ
Q1. Are you a factory and trading company?
A: We are a factory
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. Can you suggst me a suitable type?
A: Certainly, Once you give me the keyword. The most suitable size will be choose to meet your need
Q4. How about your delivery time?
A: Generally, it will take 7-30 days after receiving your advance payment. The specific delivery time depends on the items , transportation ways and the quantity of your order.
